TM-V-UNJ


  •  Thread Milling
  •  Thread Milling
  •  Thread Milling

Pitch

Insert Size

mm

L=10.4mm
D=6.0mm

L=11mm
D=1/4”

L=16mm
D=3/8”

L=22mm
D=3/8”B

L=27mm
D=5/8”

L=38.5mm
D=3/4”B

24

Ext.



2E24 UNJ

3E24 UNJ







Int.

*6N16 UNJ

2N24 UNJ

3N24 UNJ







20

Ext.



2E20 UNJ

3E20 UNJ







Int.

*6N16 UNJ

2N20 UNJ

3N20 UNJ







18

Ext.





3E18 UN







Int.

*6N16 UNJ

2N18 UNJ

3N18 UNJ







16

Ext.



2E16 UNJ

3E16 UNJ



5E16 UNJ



Int.

*6N16 UNJ

2N16 UNJ

3N16 UNJ



5N16 UNJ



14

Ext.



2N14 UNJ

3N14 UNJ







Int.



2E14 UNJ

3E14 UNJ







13

Ext.





3E13 UNJ







Int.













12

Ext.





3E12 UNJ



5E12 UNJ



Int.





3N12 UNJ



5N12 UNJ



11

Ext.









5E11 UNJ



Int.









5N11 UNJ
