Designation

IC
(D)

L

Pitch
(TPI)

X

Y

Thickness
(T)

11NR/L 20 ABUT

1/4”

11

20

1.0

1.4

3.20

11NR/L 16 ABUT

1/4”

11

16

1.3

1.9

3.20

16NR/L 20 ABUT

3/8”

16

20

1.0

1.4

3.65

16NR/L 16 ABUT

3/8”

16

16

1.3

1.9

3.65

16NR/L 12 ABUT

3/8”

16

12

1.4

2.0

3.65

16NR/L 10 ABUT

3/8”

16

10

1.5

2.3

3.65

22NR/L 8ABUT

1/2”

22

8

2.0

3.2

4.76

22NR/L 6 ABUT

1/2”

22

6

2.2

3.5

4.76
